Promat Contoured Bodied Flange Branch Fittings
PromatBD manufactures and stocks a new generation of flanged branch connections whereby
one single fitting is produced from a unique single forging to replace the 3 separate components
of a conventional 3 piece branch assembly.
The fittings provide reduced fabrication and installation costs to our customers and offer increased strength & safety and improved integrity
Promat BD contoured forged fittings have Lloyds type approval covering the following design codes:
- ANSI B31.1
- ANSI B31.3
- ANSI B31.4
- ANSI B31.8
- ASME 8
- BS 5500
We produce a range of fittings to suit different applications:
![](images/flange_1.jpg)
Weldoflange - Short length 90 degree branch connection
![](images/flange_4.jpg)
Latroflange - 45 degree angular branch connection
![](images/flange_3.jpg)
Elboflange - Centre line branch connection for pipe heads
![](images/flange_2.jpg)
Nipoflange - Extended length 90 degree branch connection
Reinforced Nipoflange - Self reinforcing fixed length 90 degree branch connection
